Prepainted Aluzinc Steel Coil, Prepainted Galvalume Steel Coil (PPGL)
Standard: ASTM/JIS/GBT/EN etc
Thickness: 0.12mm ~ 2.0mm
Width: 600mm ~ 1800mm
Shanghai Metal Corporation is a leading Prepainted Aluzinc Steel Coil, Prepainted Galvalume Steel Coil (PPGL) manufacturer and supplier.
Prepainted Aluzinc Steel Coil, also known as Prepainted Galvalume Steel Coil (PPGL), is a composite metal material consisting of a cold-rolled steel substrate, a 55% aluminum-zinc alloy coating, and a factory-applied organic paint layer. It is primarily used in construction for roofing, wall cladding, and sandwich panels, as well as in the manufacturing of home appliances like refrigerators and air conditioners. This product specifically addresses the need for enhanced durability in harsh environments by combining the superior corrosion resistance and high-temperature tolerance of the aluzinc substrate with the UV protection and aesthetic versatility of the pre-applied paint. Consequently, it effectively solves issues related to rapid rusting, paint peeling, and high maintenance costs associated with traditional uncoated metals, providing a long-lasting, low-maintenance building and manufacturing material.
If you want to know more about our steel products or Prepainted Aluzinc Steel Coil, Prepainted Galvalume Steel Coil (PPGL) price please feel free to contact us, we will reply you within 24 hours.
-
1. Steel Grade: SGCC, DX51D, S250GD, S550GD etc
2. Top paint/back paint: 5+15μm/7-9μm or 5+20μm/10-12μm
3. Zinc coating: AZ30 ~ AZ180
4. Color: Any color as per client's needs
5. Coil ID: 508mm/610mm
6. Coil weight: as per client's needs
7. Pack: vertical or horizontal package
-
-
-
1. Superior Corrosion Resistance
Combines aluminum's barrier protection with zinc's sacrificial protection, lasting 2-3 times longer than standard galvanized steel. This significantly reduces long-term maintenance and replacement costs in harsh environments.
2. Exceptional Heat Reflectivity
Reflects up to 70% of solar heat radiation. This helps maintain cooler indoor temperatures, directly reducing air conditioning energy consumption and utility costs.
3. High-Temperature Stability
Maintains coating integrity at temperatures up to 315°C. It safely withstands high-heat industrial applications like oven casings and chimneys without degrading.
4. Excellent Formability
Features superior paint adhesion that prevents peeling or cracking during bending and stamping. This ensures high manufacturing yields and reduces scrap rates for fabricators.
-
1. Industrial Roofing & Cladding
Suitable for large-span factories and warehouses. The Al-Zn coating resists rust and reflects solar heat to reduce cooling costs. Recommended Structure Al-Zn AZ150 with PVDF/HDP topcoat.
2. Coastal Construction
Suitable for marine environments. The aluminum oxide layer acts as a robust physical barrier against salt spray corrosion. Recommended Structure Al-Zn AZ150 with PVDF topcoat and 2/2 backcoat.
-
Process Flow Diagram of PPGL:
Pay off reel → double cut shear → welder-notcher → entry accumulator → pre cleaning section → furnace → hot bridle → zinc pot → air knife → after cooler → water quench → dryer → skin pass mill → dryer → tension leveler → dryer → chemical coater → chemical oven → cooler → exit accumulator → oiler → exit shear → tension reel.
1. Classifications & Sympol
|
Classifications |
Items |
Symbol |
|
Paint type |
Polyester |
PE |
|
Silicon modified polyester |
SMP |
|
|
High-durability polyester |
HDP |
|
|
Polyvinylidene fluoride |
PVDF |
|
|
Paint surface texture |
Regular prepainted |
TC |
|
Embossed sheet |
YA |
|
|
Printed sheet |
YI |
|
|
Paint structure |
One-coating-and one-baking |
2/1 |
|
Double-coating-and-double-baking |
2/2 |
2. Paint property:
|
Top paint |
Paint thickness/ μm |
Pencil hardness |
180° bend |
Impact(J) |
Salt pray resistance |
|
PE |
≥20 |
≥F |
≤4T |
≥9 |
≥1000hours |
|
SMP |
≥20 |
≥F |
≤4T |
≥9 |
≥1000hours |
|
HDP |
≥20 |
≥HB |
≤4T |
≥9 |
≥1500hours |
|
PVDF |
≥20 |
≥HB |
≤4T |
≥9 |
≥2000hours |
3.Steel Grade and Application:
|
Base metal of Prepainted steel |
Application |
||||
|
Hot-dip Zinc |
Hot-dip Zinc-Fe alloy |
Hot-dip Al-Zinc alloy |
Hot-dip Z-Al alloy |
Eletro-galvanized |
|
|
TDC51D+Z |
TDC51D+ZF |
TDC51D+AZ |
TDC51D+ZA |
TDC01+ZE |
CQ |
|
TDC52D+Z |
TDC52D+ZF |
TDC52D+AZ |
TDC52D+ZA |
TDC03+ZE |
DQ |
|
TDC53D+Z |
TDC53D+ZF |
TDC53D+AZ |
TDC53D+ZA |
TDC04+ZE |
DDQ |
|
TDC54D+Z |
TDC54D+ZF |
TDC54D+AZ |
TDC54D+ZA |
/ |
EDDQ |
|
TS250GD+Z |
TS250GD+ZF |
TS250GD+AZ |
TS250GD+ZA |
/ |
Structure |
|
TS280GD+Z |
TS280GD+ZF |
TS280GD+AZ |
TS280GD+ZA |
/ |
Structure |
|
/ |
/ |
TS300GD+AZ |
/ |
/ |
Structure |
|
TS320GD+Z |
TS320GD+ZF |
TS320GD+AZ |
TS320GD+ZA |
/ |
Structure |
|
TS350GD+Z |
TS350GD+ZF |
TS350GD+AZ |
TS350GD+ZA |
/ |
Structure |
|
TS550GD+Z |
TS550GD+ZF |
TS550GD+AZ |
TS550GD+ZA |
/ |
Structure |
4. Mechanical property:
|
Steel Grade |
Y.S/MPA |
T.S/MPA |
EL./ ≥% |
|
TDC51D+Z/ZM/AZ |
240 ~ 380 |
270 ~ 500 |
22 |
|
TDC52D+Z/ZM/AZ |
140 ~ 300 |
270 ~ 420 |
26 |
|
TDC53D+Z/ZM/AZ |
140 ~ 260 |
270 ~ 380 |
30 |
|
TDC54D+Z/ZM/AZ |
120 ~ 220 |
260 ~ 350 |
36 |
Packaging Information for Prepainted Aluzinc Steel Coil:
Standard Packaging
Each coil is wrapped with moisture-proof paper and a protective PE film, then secured with steel straps and plastic end caps. The coils are placed on reinforced fumigated wooden pallets and covered with a galvanized steel sheet to ensure safe international shipment.
Shipping
Depending on order quantity and destination, we support FCL and LCL sea freight, break-bulk vessel shipment for large-diameter sections, and road or rail land transport. Trade terms include EXW / FOB / CIF; other terms may be available upon request. Shipping costs are calculated based on maximum section diameter, gross weight, destination and the selected transportation method.
Lead Time
Drawing & technical confirmation: 5 – 10 working days
Single tower production: 30 – 45 working days
Batch orders / customized towers: 45 – 60 working days
Q. What information do you need for a custom quotation?
A. Please provide: Substrate (PPGI/PPGL), Thickness, Width, Coating Weight (e.g., AZ150), Paint System & Thickness (e.g., PE, PVDF), and Color Code (RAL).
Q. What is the MOQ and production lead time?
A. MOQ is typically 25 MT per color/size. Lead time is 15–25 days after receiving the deposit or original L/C.
Q. What quality standards does the product meet?
A. Products comply with EN 10346, ASTM A653, and JIS G 3322. Third-party inspections (e.g., SGS, BV) are supported.
Q. What factors should I consider when choosing between PPGI and PPGL?
A. Choose PPGI for dry, inland, or budget-sensitive projects. Choose PPGL for coastal, high-humidity, or industrial environments due to its superior corrosion resistance and heat reflectivity.
Q. How do I select the correct paint coating for my specific environment?
A. PE: Cost-effective for standard inland construction.
SMP/HDP: Better UV and color retention for harsh sunlight.
PVDF: Premium choice for extreme weather, coastal, or chemical environments.
Q. What is the maximum heat resistance of PPGL for industrial applications?
A. The 55% Al-Zn substrate withstands continuous temperatures up to 315°C. We recommend using high-temperature SMP or specialized heat-resistant paint for oven casings and chimneys.
