Grade: WRe3%, WRe5%, WRe25%, WRe26%



    Diameter: φ1-φ35mm

Shanghai Metal Corporation is a leading tungsten rhenium rod manufacturer and supplier.

The tungsten-rhenium alloy is a solid solution-strengthened alloy composed of a tungsten element and a cerium element.The cerium content (mass fraction, %) commonly used in alloys is 3, 5, 10, 25 and 26. Low content of W-Re alloy (Re ≤ 5%) and high content of W-Re alloy (Re ≥ 15%).

The main processed materials of tungsten-rhenium alloy are wire and sheet. Silk is the majority. Mainly used as high temperature structural materials.

Tungsten-rhenium alloy has better mechanical properties and ductility than pure tungsten, and has high electrical resistivity, so it has good processability and weldability. A tungsten-rhenium alloy containing 3% can be used as a core metal for the tube filament, the grid wire, and the direct heating cathode.

The antimony-containing tungsten-rhenium alloy, that is, the antimony-tungsten-rhenium alloy, is used as a direct-heating cathode of a large-sized launch tube, and its performance is better than that of a tantalum-tungsten cathode, and it is not easily deformed at a high temperature.

If you want to know more about our Rare Metal(Indium,Nickel,Molybdenum,etc.) products or tungsten rhenium rod price please feel free to contact us, we will reply you within 24 hours.


  • 1) Grade: WRe3%, WRe5%, WRe25%, WRe26%

    2) Diameter: φ1-φ35mm

    3) Length: 10mm, 20mm, 50mm, 100mm, 200mm, 300mm, 500mm

  • 1) Better mechanical properties and ductility

    2) Excellent high temperature ductility

    3) Strong resistance to chemical corrosion

    4) Good thermal shock resistance

    5) Good oxidation resistance at high temperature

    6) Over a wide temperature range with high resistivity


  • 1)Aerospace: Tungsten-rhenium alloys are applied in high-temperature aviation and aerospace parts and temperature measurement systems.

    2)Industrial furnaces: high temperature components and temperature measurement device.

    3)Welding industry: Friction Stir Welding Head

  • 1) Hardness

    2) Tensile Strength

    3) Elongation

    4) Metal-Detector

    5) Conductivity

    6) Chemical Content

Technical Information of Tungsten Rhenium Rod

Grade: WRe3%, WRe5%, WRe25%, WRe26%

Diameter: φ1-φ35mm

Length: 10mm, 20mm, 50mm, 100mm, 200mm, 300mm, 500mm





Packaging of Tungsten Rhenium Rod

Shanghai Metal Products are packed and labeled according to the regulations and customer's requests. Great care is taken to avoid any damage which might be caused during storage or transportation. In addition, clear labels are tagged on the outside of the packages for easy identification of the product I. D. and quality information.

1) Shanghai Metal Standard

2) Customization



Application of Tungsten Rhenium Rod:

Because of its superior high-temperature performance, tungsten-rhenium alloy can be applied in the parts used in high-temperature areas and temperature measurement applications, mainly including:

1)Aerospace: Tungsten-rhenium alloys are applied in high-temperature aviation and aerospace parts and temperature measurement systems.

Semiconductor industry: Due to its superior physical properties, tungsten-rhenium alloy is used in the high temperature equipment parts for the semiconductor industry, such as heating equipment and temperature measurement equipment, etc.

 2)Industrial furnaces: high temperature components and temperature measurement device.

3)Welding industry: Friction Stir Welding Head



Condition of Tungsten Rhenium Rod:

WRe is applied to 9~2300 temperature in vacuum, incert and reducing atmosphere, and also used as molten steel rapid temperature measurement probe. Anti oxidation WRe thermocouple replacing Pt Rh thermocouple, the application is extremely broad.
