Inconel Series

Inconel 601

    Model Number: Inconel 601

    Shape: Forging & Cold Drawn

    Standard: ASTM ASME


1. ASTM Standard Of Products


2. Chemical composition


3. Physical properties

Shanghai Metal Products are packed and labeled according to the regulations and customer's requests. Great care is taken to avoid any damage which might be caused during storage or transportation.

In addition, clear labels are tagged on the outside of the packages for easy identification of the product I. D. and quality information.

1)Shanghai Metal Standard




1. Hot and Cold Forming

The temperature range for hot-forming INCONEL alloy 601 is 1600-2250°F (870-1230°C). Hot-working operations involving large deformations should be performed at 1900-2250°F (1040-1230°C). The alloy has low ductility at temperatures from 1200 to 1600°F (650-870°C) and should not be worked in that range. Light working at temperatures below 1200°F (650°C) can be done to develop high tensile properties. The material was hot-worked from 6-in. (152- mm) diameter rounds to 4-in. (102-mm) squares and air-cooled. Transverse specimens from the centers of the bars were used for the tests. The rate of cooling following hot-working is not critical with respect to thermal cracking. To avoid sensitization, however, the alloy should be cooled rapidly through the 1000-1400°F (540-760°C) temperature range.

2. Machining

All standard machining operations are readily performed on INCONEL alloy 601. For the best

machinability, the alloy should be in the solution-treated condition.

3. Joining

INCONEL alloy 601 exhibits good weldability and is readily joined by conventional welding products and processes. Welding products are available which provide high joint efficiencies and heat resistance. The choice of welding product is dependent upon the service conditions to which the fabricated alloy 601 component will be exposed.
