The origins of the use of arches as a structural form in buildings can be traced back to antiquity (Van Beek, 1987). In trying to arrive at a suitable definition for an arch we may look no further than Hooke’s anagram of 1675 which stated ‘Ut pendet continuum flexile, sic stab at continuum rigidum inversum’ – ‘as hangs the flexible line, so but inverted will stand the rigid arch’. This suggests that any given loading to a flexible cable if frozen and inverted will provide a purely compressive structure in equilibrium with the applied load. Clearly, any slight variation in the loading will result in a moment being induced in the arch. It is arriving at appropriate proportions of arch thickness to accommodate the range of eccentricities of the thrust line that is the challenge to the bridge engineer.
Indeed, even in the Middle Ages it was valued that brick work curves carried on basically as gravity structures, for which geometry and extent directed tasteful request and dependability. Compressive quality could be depended upon whilst rigidity proved unable. Based upon experience, numerous exact connections between the range and curve thickness were created and connected effectively to deliver numerous exquisite structures all through Europe. The development of the railroad and waterway frameworks prompted a blast of extension building.
Brickwork curves turned out to be progressively well known. With the development of the Coalbrookdal Bridge (1780) another period of curve scaffold development started. Before the end of the nineteenth century cast iron, fashioned iron lastly steel turned out to be progressively prominent; just to be tested by ferro bond (strengthened cement) when the new century rolled over.
During the nineteenth century analytical technique developed apace. In particular, Castigliano (1879) developed strain energy theorems which could be applied to arches provided they remained elastic. This condition could be satisfied provided the line of thrust lay within the middle third, thus ensuring that no tensile stresses were induced.The requirement to avoid tensile stresses only applied to masonry and cast iron; it did not apply to steel or reinforced concrete as these materials were capable of resisting tensile stresses.
Types of arch bridge
There are many different types and arrangements of arch bridges. A deck arch is one where the bridge deck which includes the structure that directly supports the traffic loads is located above the crown of the arch. The deck arch is also known as a true or perfect arch. A through-arch is one where the bridge deck is located at the spring line of the arch. A half-through arch is where the bridge deck is located at an elevation between a deck arch and a through arch. A further classification refers to the articulation of the arch. A fixed arch implies no rotation possible at the supports, A and B. A fixed arch is indeterminate to the third degree. A three-hinged arch that allows rotation at A, B, and C is statically determinate. A two-hinged arch allows rotation at A and B and is indeterminate to one degree.
